Servo Motor, 460V, 115mm, 76.2mm, 5000rpm, Inc.Encoder, IP66, no brake, IEC Metric, Allen-Bradley

Name: Servo Motor
Brand: Allen-Bradley
SKU: MPL-B430P-HJ72AA
Price: 1 656.80 EUR
Availability: InStock

MP-Series™ Low-Inertia Motors
The Allen-Bradley® MP-Series Low-Inertia, high-output brushless servo motors use innovative design characteristics to reduce motor size while delivering significantly higher torque. These compact and highly dynamic brushless servo motors from Rockwell Automation are designed to meet the demanding requirements of high-performance motion systems. This series of servo motors is typically used with the Allen-Bradley Kinetix® 6000, Kinetix 6200, Kinetix 6500, Kinetix 300, and Kinetix 350 servo drive families. Available in nine frame sizes, these motors provide continuous stall torque from 0.26 to 163 Nm (2.3-1440 lb-in.) and peak torque from 0.77 to 278 Nm (6.8-2460 lb-in.)

MP-Series Low-Inertia Motors Provide:
Innovative winding technology yields up to 40% higher torque per unit size than conventional servo motors

Improved winding insulation material for enhanced thermal management and heat transfer, resulting in higher performance

High-energy rare-earth magnets for quicker acceleration

New SpeedTEC DIN connectors allow flexible orientation of connectors and use of a single cable family with all MP-Series motors

Integral 24-volt brake option

Broad torque range – all within one motor family

Optional Shaft Seal for IP 66 environmental rating

Standard IEC 72-1 mounting dimensions

Operating temperature range: 0 - 40° C (32 - 104° F)

The MP-Series Low-Inertia Motors are UL recognized components to applicable UL and CSA standards and CE marked for all applicable directives

High-Performance Feedback

MP-Series Low-Inertia motors are available with high performance encoders with a choice of single-turn or multi-turn high-resolution feedback.

Up to 2 million counts per revolution for smooth performance and precise control (MPL-A/B3xx, -A/B4xx, -A/B45xx, -A/B5xx, -B6xx, -B8xx, and -B9xx motors)

Up to 260 thousand counts per revolution for smooth performance and precise control (MPL-A/B15xx and -A/B2xx motors)

Multi-turn encoder provides high-resolution absolute position feedback within 4096 turns. The electromechanical design does not require a battery

MP-Series servo motors with high resolution encoders may be used as a component of the Kinetix safe-off feature

Smart Motor Technology

On-board memory retains motor identity

Communication link automatically reports identity to the system upon startup for reduced commissioning time
